60cbm LPG Storage Tank Liquid Propane Ammonia Butane Gas Bullet Tank for Gas Station

    Buy cheap 60cbm LPG Storage Tank Liquid Propane Ammonia Butane Gas Bullet Tank for Gas Station from wholesalers

    Buy cheap 60cbm LPG Storage Tank Liquid Propane Ammonia Butane Gas Bullet Tank for Gas Station from wholesalers
    • Buy cheap 60cbm LPG Storage Tank Liquid Propane Ammonia Butane Gas Bullet Tank for Gas Station from wholesalers
    • Buy cheap 60cbm LPG Storage Tank Liquid Propane Ammonia Butane Gas Bullet Tank for Gas Station from wholesalers
    • Buy cheap 60cbm LPG Storage Tank Liquid Propane Ammonia Butane Gas Bullet Tank for Gas Station from wholesalers
    • Buy cheap 60cbm LPG Storage Tank Liquid Propane Ammonia Butane Gas Bullet Tank for Gas Station from wholesalers
    • Buy cheap 60cbm LPG Storage Tank Liquid Propane Ammonia Butane Gas Bullet Tank for Gas Station from wholesalers
    • Buy cheap 60cbm LPG Storage Tank Liquid Propane Ammonia Butane Gas Bullet Tank for Gas Station from wholesalers

    60cbm LPG Storage Tank Liquid Propane Ammonia Butane Gas Bullet Tank for Gas Station

    Ask Lasest Price
    Brand Name : CLW
    Model Number : ASME,CCC,SGS,BV
    Certification : CLW9522
    Price : negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 500 Units/Month
    Delivery Time : 20~30 days after receiving deposit
    • Product Details
    • Company Profile

    60cbm LPG Storage Tank Liquid Propane Ammonia Butane Gas Bullet Tank for Gas Station

    60cbm LPG Storage Tank Liquid Propane Ammonia Butane Gas Bullet Tank for Gas Station


    Product Description


    1. Storage medium of lpg gas plant tank : LPG, Liquid ammoina,Dimethyl ether,Iso-butane,Pentane and etc.
    2. Available tank capacity of lpg gas plant tank : 5m³~200m³,2ton~100tons
    3. Manufacturing standards of lpg gas plant tank : GB-150, ASME VIII Division I U STAMP, CCC, ISO9001 : 2008
    4. Optional for lpg gas plant equipments as follows, lpg pump and motor,lpg compressor,volume flow meter,filling scales and lpg dispenser,ball valves,check valves,non-return valves,glass valve,strainer,by-pass valve and so on.


    Specification of 30mt filling station gas tank

    Parameter of 60000liters 30tons filling station gas tank
    ITEMPARAMETERITEMPARAMETER
    Volume60cbmThickness of Shell14mm
    Tank MaterialQ345RThickness of End plate16mm
    Overall Size10962*2728*3318mmTank Net Weight12750kg
    Tank Diameter2700mmLoading Capacity23940kg
    Design Pressure1.77MpaGas Density420kg/M3
    Hydraulic Test Pressure2.22MpaCorrosion Allowance1mm
    Design Temperature-20ºC~60ºCHeat TreatmentBulk
    Vapor OutletDN50Gas OutletDN50
    Life time15 years
    Accessories
    ModelItemQtyJunction surface
    J41N-2.5-50Stop Valve DN506RF
    J41N-2.5-25Stop Valve DN252RF
    J41N-2.5-100Stop Valve DN1001RF
    J24W-320-DN6J24W Needle Valve M20*1.51
    HG21584-95Magnetic plate level Gauge UZFAL-2.5RF-3040-0.51RF
    A42F-25-100Safety Valve DN1001RF
    Y-100TPressure Gauge M20*1.5 1.5degree 0~4Mpa1
    WTQ-280Thermometer M33*2 2.5 degree1-40ºC~60ºC

    Quality 60cbm LPG Storage Tank Liquid Propane Ammonia Butane Gas Bullet Tank for Gas Station for sale
